MT573CPS

Key Features

• Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
• Standard Fully Synchronized Transmission & 20 x 20 (With Creep) Powershuttle – Change gears without having to stop. 20 forward / 20 reverse gear transmission provides more operating speeds than others in its class for superior control, precision and safe operations for virtually any application. CPS models feature 20×20 (with creep) Powershuttle.
• Hand Clutch – The hand clutch button added to the gear control lever enables you to change gears easily and with comfort.
• Roomy Cab With AC/Heat – Comes standard with side mirrors, front washer/wiper, interior lighting, air conditioning and heat, flat platform and rubber mat.
• Standard 3 Sets Of Remote Valves With Detent – Adds functionality and improves ease of use by allowing attachment of hydraulically controlled implements without the high, additional costs like others in its class to add the remotes as options.
• Extendable Lower Links – Allows easier attachment of a wide variety of implements with a 6,614 lb. lift capacity.
• Large Fuel Tank – Provides long operation times between fill ups.
• Your Choice Of Tires – Available with several tire combinations to choose from as standard equipment, as well as optional Goodyear Titan R14 tires.
• Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
• Fender Mounted Joystick For Front End Loader – Easily accessible for maximum comfort and convenience.
• LS CRDI Tier 4 Engine – Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
• Modern Ergonomic Design – Ergonomically designed for comfort.
• Standard Rear Work Light – Adjustable light to improve visibility where you need it.
• Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
• 7 Pin Connector – Provides electrical power for implements when needed.

Specifications

Engine

Type	Vertical Water-Cooled 4-Cycle Diesel Engine
Model (Tier 4)	L4C25-T
Engine HP (Gross)	73
PTO HP	62
Rated Speed (RPM)	2,500
Displacement (cu. in)	152.9
Fuel Tank Capacity (gal)	26.4

Drive Train

Transmission Type	Power Shuttle
No. of Speed	F20 x R20
Forward speed (mph)	0.11 ~ 19.4

PTO

Type	Independent
Rear, rpm	540 / 750 / 1,000

Hydraulic System

Control System	Position/Draft
Implement pump (gpm)	13.2
Steering pump (gpm)	6.6
Total flow (gpm)	19.8
Category, 3 pt hitch	CAT II
Hitch Lift capacity, lbs (Hitch end)	6,614
Remote Valves	3 pairs (Front), 3 pairs (Rear)

Dimension

Overall length (Frame to Link, in.)	150
Wheelbase (in.)	84.6
Min. overall width with tires (in.)	77.5
Height to top (in.)	104.4

Tire Size

Front	11.2 – 24
Rear	16.9 – 30

Weight

Total weight without ballast (lbs.)

6,669
