MT355E/HE

Key Features

• 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
• Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
• Dual Pedal, 3 Range HST – Easier and more comfortable than rocker pedals. Includes cruise control.
• Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
• Fender Mounted Joystick For Front End Loader – Easily accessible for maximum comfort and convenience.
• Standard Foldable ROPS – Allows Storage in low clearance buildings or sheds.
• Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
• 3-Point Hitch – Category 2 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
• Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
• Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
• Large Fuel Tank – 7.4 gallon capacity provides long operation times between fill ups.
• Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
• LS CRDI Tier 4 Engine – Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
• Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
• Modern Ergonomic Design – This compact is ergonomically designed.
• Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.

Specifications

Engine





Type	Vertical Water Cooled 4 Cycle Diesel Engine
Model (Tier 4)	L3C19-T
Engine HP (Gross)	55
PTO HP	44.0 – 46.7
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	13.7

Drive Train

Transmission Type	Synchro Shuttle/Constant Mesh
No. of Speed	F8 × R8
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO

Type	Independent
Rear, rpm	540 (Standard)

Hydraulic System

Control System	Position
Implement pump (gpm)	8.2
Steering pump (gpm)	4.8
Total flow (gpm)	13.0
Category, 3 pt hitch	CAT 2
Hitch Lift capacity, lbs (Hitch end)	2,910
Remote Valves	2 pairs (Front), 1/2 pairs (Rear, Option)

Dimension

Overall length (Frame to Link, in.)	125
Overall width with tires (in.)	68
Wheelbase (in.)	74.8
Height to top (in.)	100

Tire Size

Ag Front / Rear	9.5-16 / 14.9-24
IND Front / Rear	10.0-16.5 / 17.5L-24
Turf Front / Rear	29 x 12.50-15 / 44 x 18.00-20
Narrow Ag Front / Rear	7.0 – 14 / 9.5 – 24

Weight

Total weight without ballast (lbs.)

3,724
