Key Features

• 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
• Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
• Dual Pedal, 3 Range HST – Easier and more comfortable than rocker pedals. Includes cruise control.
• Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
• Fender Mounted Joystick For Front End Loader – Easily accessible for maximum comfort and convenience.
• Standard Foldable ROPS – Allows Storage in low clearance buildings or sheds.
• Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
• 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
• Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
• Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
• Large Fuel Tank – 7.4 gallon capacity provides long operation times between fill ups.
• Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
• LS CRDI Tier 4 Engine – Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
• Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
• Modern Ergonomic Design – This compact is ergonomically designed.
• Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.

Specifications

Engine

Type	3-cylinder, CRDI, liquid-cooled, Diesel, NA
Model (Tier 4)	L3C19-T
Engine HP (Gross)	40
PTO HP	34
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	7.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	Synchro Shuttle
No. of Speed	3 Ranges
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO

Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position
Implement pump (gpm)	8.2
Steering pump (gpm)	5.5
Total flow (gpm)	13.7
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	121
Overall width with tires (in.)	69
Wheelbase (in.)	54
Height to top (in.)	88

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

2,881

Key Features

• Left And Right Cab Doors – Premium Seat Providing Access To Either Side Of The Cab
• 3 Range Hydrostatic Transmission – Provides Comfort And Excellent Controllability Of Tractor Movement
• 3 Standard Dual Mirrors – Provide Added Visibility
• 3 Standard Drawbar – Provides Value And Enables Trailering etc.
• 3 Ground Level Fueling – Provides Easy Access.
• Standard Grille Guard With Loader – Provides Added Protection
• High-Capacity Loader – With High Lift Height And Standard Skid Steer Coupler
• Standard Integrated Joystick – Mid Mount Valve, Providing Deluxe Fit And Finish
• Electronic PTO – For Ease Of Use

Specifications

Engine

Type	Vertical Water-Cooled 4Cycle Diesel Engine
Model (Tier 4)	L3C19-T
Engine HP (Gross)	40
PTO HP	32
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	12.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	HST
No. of Speed	3 Ranges (HST)
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO

Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position/Draft
Implement pump (gpm)	8.2
Steering pump (gpm)	5.5
Total flow (gpm)	13.7
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	128.3
Overall width with tires (in.)	69
Wheelbase (in.)	62
Height to top (in.)	86.6

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

3,661

Key Features

• 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
• Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
• Dual Pedal, 3 Range HST – Easier and more comfortable than rocker pedals. Includes cruise control.
• Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
• Fender Mounted Joystick For Front End Loader – Easily accessible for maximum comfort and convenience.
• Standard Foldable ROPS – Allows Storage in low clearance buildings or sheds.
• Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
• 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
• Ergonomically Designed 3-Point Hitch Controls – Easily accessible for maximum comfort and convenience with hydraulic position control.
• Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
• Large Fuel Tank – 7.4 gallon capacity provides long operation times between fill ups.
• Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
• LS CRDI Tier 4 Engine – Generates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
• Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
• Modern Ergonomic Design – This compact is ergonomically designed.
• Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.

Specifications

Engine

Type	3-cylinder, CRDI, liquid-cooled, Diesel, NA
Model (Tier 4)	L3C19-D2
Engine HP (Gross)	35
PTO HP	28
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	7.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	HST
No. of Speed	3 Ranges
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO

Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position
Implement pump (gpm)	8.2
Steering pump (gpm)	5.5
Total flow (gpm)	13.7
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	121
Overall width with tires (in.)	69
Wheelbase (in.)	54
Height to top (in.)	88

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

2,870

Key Features

• Left And Right Cab Doors – Premium Seat Providing Access To Either Side Of The Cab
• 3 Range Hydrostatic Transmission – Provides Comfort And Excellent Controllability Of Tractor Movement
• 3 Standard Dual Mirrors – Provide Added Visibility
• 3 Standard Drawbar – Provides Value And Enables Trailering etc.
• 3 Ground Level Fueling – Provides Easy Access.
• Standard Grille Guard With Loader – Provides Added Protection
• High-Capacity Loader – With High Lift Height And Standard Skid Steer Coupler
• Standard Integrated Joystick – Mid Mount Valve, Providing Deluxe Fit And Finish
• Electronic PTO – For Ease Of Use

Specifications

Engine

Type	Vertical Water-Cooled 4Cycle Diesel Engine
Model (Tier 4)	L3C19-T
Engine HP (Gross)	35
PTO HP	28
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	12.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	HST
No. of Speed	3 Ranges (HST)
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO

Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position/Draft
Implement pump (gpm)	8.2
Steering pump (gpm)	5.5
Total flow (gpm)	13.7
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	128.3
Overall width with tires (in.)	69
Wheelbase (in.)	62
Height to top (in.)	86.6

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

3,655

Key Features

• Left And Right Cab Doors – Premium Seat Providing Access To Either Side Of The Cab
• 3 Range Hydrostatic Transmission – Provides Comfort And Excellent Controllability Of Tractor Movement
• 3 Standard Dual Mirrors – Provide Added Visibility
• 3 Standard Drawbar – Provides Value And Enables Trailering etc.
• 3 Ground Level Fueling – Provides Easy Access.
• Standard Grille Guard With Loader – Provides Added Protection
• High-Capacity Loader – With High Lift Height And Standard Skid Steer Coupler
• Standard Integrated Joystick – Mid Mount Valve, Providing Deluxe Fit And Finish
• Electronic PTO – For Ease Of Use

Specifications

Engine

Type	Vertical Water-Cooled 4Cycle Diesel Engine
Model (Tier 4)	L3C19-T
Engine HP (Gross)	35
PTO HP	29.7
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	12.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	Synchro Shuttle
No. of Speed	F12 X R12
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO



Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position/Draft
Implement pump (gpm)	8.2
Steering pump (gpm)	4.1
Total flow (gpm)	12.3
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	128.3
Overall width with tires (in.)	69
Wheelbase (in.)	62
Height to top (in.)	86.6

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

3,589

Key Features

• 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
• Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
• Standard 12×12 Synchro Shuttle – Makes changing direction easier than competitive non-shuttle gear models. 12 forward / 12 reverse gear transmission provides more operating speeds than others in its class for superior control, precision and safe operations for virtually any application.
• Side Mounted Main Gear – Maximizes space and makes getting on and off tractor easier than straddle type like other brands.
• Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
• Standard Foldable Rops – Allows Storage in low clearance buildings or sheds.
• Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
• 3-Point Hitch – Introducing foldable ROPS for storage allowance in low clearance buildings or sheds.
• 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
• Ergonomically Designed 3-Point Hitch – Easily accessible for maximum comfort and convenience with hydraulic position control.
• Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
• Large Fuel Tank – 7.4 gallon capacity provides long operation times between fill ups.
• Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
• LS Tractor Tier 4 Engine – TGenerates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
• Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
• Modern Ergonomic Design – This compact is ergonomically designed.
• Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.

Specifications

Engine

Type	3-cylinder, indirect-injection, Water-cooled, Diesel, NA, CRDI
Model (Tier 4)	L3C19-D2
Engine HP (Gross)	35
PTO HP	29.7
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	7.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	Synchro Shuttle
No. of Speed	F12 X R12
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO



Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position
Implement pump (gpm)	8.2
Steering pump (gpm)	4.1
Total flow (gpm)	12.3
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	121
Overall width with tires (in.)	69
Wheelbase (in.)	54
Height to top (in.)	88

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

2,866

Key Features

• 4WD (Front Wheel Mechanical Assist) – Go from 2WD to a 4WD with a simple move of a lever.
• Independent PTO – Easiest PTO to operate that can be turned on or off with a switch.
• Standard 12×12 Synchro Shuttle – Makes changing direction easier than competitive non-shuttle gear models. 12 forward / 12 reverse gear transmission provides more operating speeds than others in its class for superior control, precision and safe operations for virtually any application.
• Side Mounted Main Gear – Maximizes space and makes getting on and off tractor easier than straddle type like other brands.
• Standard Tilt & Power Steering – Makes turning easier, improves control and reduces fatigue.
• Standard Foldable Rops – Allows Storage in low clearance buildings or sheds.
• Your Choice Of Tires At No Additional Cost – Choose Ag, Industrial or Turf tires at no additional cost. *Subject to dealer inventory.
• 3-Point Hitch – Introducing foldable ROPS for storage allowance in low clearance buildings or sheds.
• 3-Point Hitch – Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements.
• Ergonomically Designed 3-Point Hitch – Easily accessible for maximum comfort and convenience with hydraulic position control.
• Standard Draw Bar – Increases the usefulness of the tractor without the additional optional cost.
• Large Fuel Tank – 7.4 gallon capacity provides long operation times between fill ups.
• Standard Rubber Mat – Reduces noise, vibration and prevents slipping.
• LS Tractor Tier 4 Engine – TGenerates more power with less noise, fuel consumption, vibration and emissions. Standard preheat starting aid helps starting in cold weather.
• Easy Open One-Piece Hood – Easy access for maintenance of this low emissions, fuel efficient engine. Standard pre-heat starting aid improves starting in cold weather.
• Modern Ergonomic Design – This compact is ergonomically designed.
• Adjustable Seat With Seat Belt – Keeps you in a comfortable and safe position for maximum control.

Specifications

Engine

Type	3-cylinder, indirect-injection, Water-cooled, Diesel, NA, CRDI
Model (Tier 4)	L3C19-D3
Engine HP (Gross)	35
PTO HP	25.5
Rated Speed (RPM)	2,600
Displacement (cu. in)	114.7
Fuel Tank Capacity (gal)	7.4
Alternator (V-A)	12V – 70 Amps

Drive Train

Transmission Type	Synchro Shuttle
No. of Speed	F12 X R12
Brakes	Wet, Multi-disc
Steering	Hydrostatic Power Steering

PTO



Type	Independent
Rear, rpm	540 (Standard)
Mid, rpm	2,000 (Option)

Hydraulic System

Control System	Position
Implement pump (gpm)	8.2
Steering pump (gpm)	4.1
Total flow (gpm)	12.3
Category, 3 pt hitch	CAT I
Hitch Lift capacity, lbs (Hitch end)	1,808
Remote Valves	Option

Dimension

Overall length (Frame to Link, in.)	121
Overall width with tires (in.)	69
Wheelbase (in.)	54
Height to top (in.)	88

Tire Size

Ag Front / Rear	7 – 14 / 11.2 – 24
IND Front / Rear	27X8.50-14 / 43X16.00-20
Turf Front / Rear	25X8.50-14 / 41X14.00-20

Weight

Total weight without ballast (lbs.)

2,866
